TECHNICAL SPECIFICATION Type Frequency response Power handling capacity Impedance Recommended input power Dispersion Sensitivity Peak SPL (1m) Components Connectors Rigging/Fittings . Enclosure Sealing Colours Front protection Weight Dimensions Subwoofer System-controller Optional accessories |
DIRECTOR TOP 2-way mid/high twincoaxial top, hornloaded 120 Hz – 18 kHz, +/- 3 dB MF 700 W, HF 70 W IEC norm 268-5 MF 8 ohms, HF 8 ohms MF 750 – 1500 W into 8 ohms, HF 70 – 280 W into 8 ohms 60° x 40°, horizontal and vertical symmetrical 108 dB (1 W / 1 m) > 138 dB 2 x 12“; 1 x 1,4“ N/DYM 2 x CACOM 8-pin (2 x Neutrik NL8 Speakon on request) GAE CF4 suspension points for hoisting with HWSPB studs; kelping strap brackets for tilting when flown; 4 x 100mm wheels on the back; 6 handling recesses; non-abrasive feet Multi-layered birch-ply (18 mm enclosure, 36 mm baffle) Environment-friendly structure varnish on water-basis, non-abrasive Standard black, equivalent to RAL9005, other colours on request Solid frontgrill, backed with acoustic foam 90 kgs 1000 x 600 x 600 (mm), H x W x D GAE Director Bass or GAE Director Single-Bass Setup settings for modern digital controllers GAE CF4 fittings, front protection |
TECHNICAL SPECIFICATION Type Frequency response Power handling capacity Impedance Recommended input power Dispersion Sensitivity Peak SPL (1m) Components Connectors Rigging/Fittings . Enclosure Sealing Colours Front protection Weight Dimensions System-controller Optional accessories |
DIRECTOR BASS Vented subbass enclosure 45 Hz – 250 Hz (- 3 dB) 2000 W IEC norm 268-5 4 ohms nominal 1500 – 3000 W into 4 ohms Spherical 100 dB (1 W / 1 m) > 135 dB 2 x 18“ long excursion woofer 2 x CACOM 8-pin (2 x Neutrik NL8 Speakon on request) GAE CF4 suspension points for hoisting with HWSPB studs; kelping strap brackets for tilting when flown; 4 x 100mm wheels on the back; 6 handling recesses; non-abrasive feet; Multi-layered birch-ply (18 mm enclosure, 24 mm baffle) Environment-friendly structure varnish on water-basis, non-abrasive Standard black, equivalent to RAL9005, other colours on request Solid frontgrill, backed with acoustic foam 80 kgs 1000 x 600 x 600 (mm), H x W x D Setup settings for modern digital controllers GAE CF4 fittings, front protection |
